Overview
Built for plant air rather than panel air. This unit moves 330–380 m³/h through a wall or duct stub, so it suits machine housings, small workshops and back-of-house spaces where the air has to be exchanged rather than gently stirred.
Eight models cover 115 V, 230 V and 380 V at 50 and 60 Hz, all on a 30 W motor. Noise runs at 65–68 dB(A) at one metre, which is normal for this airflow class and the reason the mounting position matters as much as the fan choice.
Where it fits
- Small workshops, plant areas and service rooms
- Machine housings with a wall or panel opening
- Wall exhaust where a short duct run is acceptable
- Utility rooms that need routine air exchange
Specifications
| MODEL | Voltage (VAC) | Frequency (Hz) | Current (AMP) | Power (W) | Speed (RPM) | Air Flow (m3/hr) | Air Flow (CFM) | Noise Lp:dB(A) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|
| HA1606001HB-1 | 115 | 50 | 0.32 | 30 | 2500 | 330 | 194 | 65 | 0.7 |
| HA1606001HB-2 | 115 | 60 | 0.32 | 30 | 2800 | 380 | 223 | 68 | 0.7 |
| HA1606002HB-1 | 230 | 50 | 0.15 | 30 | 2500 | 330 | 194 | 65 | 0.7 |
| HA1606002HB-2 | 230 | 60 | 0.15 | 30 | 2800 | 380 | 223 | 68 | 0.7 |
| HA1606003HB-1 | 380 | 50 | 0.09 | 30 | 2500 | 330 | 194 | 65 | 0.7 |
| HA1606003HB-2 | 380 | 60 | 0.09 | 30 | 2800 | 380 | 223 | 68 | 0.7 |
| HA1606003HB-3 | 380 | 50 | 0.1 | 30 | 2500 | 330 | 194 | 65 | 0.7 |
| HA1606003HB-4 | 380 | 60 | 0.1 | 30 | 2800 | 380 | 223 | 68 | 0.7 |
Selection and installation notes
The 380 V models need three-phase supply and protection; the 115 V and 230 V versions suit single-phase installations. Confirm the supply and the starting current with your electrician before ordering.
At 65–68 dB(A), this fan is audible in a quiet room. Use anti-vibration mounts, keep the unit off thin metal sheeting, and place it where the noise does not carry into a work area.
FAQ
What is this fan used for?
Plant and machine ventilation where 330–380 m³/h is needed through a wall or short duct: workshops, service rooms and equipment housings.
How loud is it?
65 dB(A) at 50 Hz and 68 dB(A) at 60 Hz at one metre. The 60 Hz version moves more air and is correspondingly louder.
Can it be ducted?
Only on short, low-resistance runs. Longer ducts and bends need a centrifugal or duct fan that can hold pressure.
Which voltages are available?
115 V, 230 V and 380 V, each at 50 Hz and 60 Hz.
